Transfer components

Components

Status badge

Communicates the current state of a transfer. Uses color, a dot, an icon, and a text label — never color alone, and never a dot alone. A dot is the same shape for all six statuses, so the dot reinforces the color and the icon is what carries meaning under a color vision deficiency.

Sent is not completed

This is the most important distinction in the product. Sent means the money left Senco. Completed means the recipient has it. In cross-border transfer those can be two days apart, and a payment that is "sent" can still fail at the receiving bank.

Green is reserved for completed. Using it for sent tells a user their family has the money when it may not arrive — and it is the single failure that would cost the most trust.

This is the canonical status table for the system. Status indicators describes when each status applies; this table defines what each one renders as. Where the two disagree, this table wins.

What each one means to the user:

Three things in that table are deliberate and easy to get wrong:

• Sent and Processing render identically. Same background, same text, same dot. They are distinguished only by icon and label — which is exactly what triple signaling is for, and it is why the icon is not optional here.
• Every colour is a semantic token, so the badge needs nothing from the theme. Text uses the feedback set's text token; dot and icon use its icon token. The dark theme remaps all of them. An earlier version took text and dot from Base ramp steps, which dark mode by rule never remaps — the background went dark and the text did not, and dark-mode Pending measured 1.72:1.
• Cancelled uses the neutral surface. No neutral feedback set exists, so it composes --ds-surface and --ds-muted, both remapped by the theme. Its chip edge against the page is faint (1.10:1 light, 1.22:1 dark). That is accepted on the same grounds as the feedback borders in Color: the icon and the label identify the status, not the chip's edge.

Verified contrast

Measured from the token values in both themes. Text needs 4.5:1; dot and icon need 3:1.

Anatomy

Dot, icon, label, then an optional timestamp, in that order along the inline axis. Dot, icon, and label render in every size; the dot reinforces the colour and the icon carries the meaning.

The compact padding (3px, 10px) and gap (6px) sit off the 4px spacing scale. They are the values that fit a 60px transaction row, and they are recorded in Known gaps rather than rounded to a scale step that would not fit.

The Processing icon does not rotate inside a badge. A badge reports a transfer's state; it is not a loading indicator for something the user is waiting on, and a list of rotating icons is motion with no information in it.

Variants

API

type TransferStatus =
  | "pending" | "processing" | "sent"      // non-terminal
  | "completed" | "failed" | "cancelled";  // terminal

interface StatusBadgeProps {
  status: TransferStatus;
  since?: Date;                     // entered-this-status timestamp; renders "Pending since 10:42"
  size?: "compact" | "default";     // default: "compact" — compact is the list-row form
  announce?: boolean;               // default: false — true only where this badge owns the live announcement
  subject?: string;                 // required when announce is true — "Transfer to Maria Santos"
}

Announcements are polite, except a change to failed, which is assertive. A failure is the one status change that alters what the user should do next.

Rendering comes from the canonical status table above. The component holds no colour logic of its own.

States

The six statuses above are the states. A badge has no hover, focus, or pressed state — it is not a control. since renders inside it; the value updates in place without re-announcing.

Behavior

Renders from the canonical table and holds no colour logic. since updates in place without re-announcing. A status change announces only when announce is set, so a row and its badge never both speak.

Content

Sentence case, one word where possible: "Completed", not "COMPLETED" and not "Successfully completed".

Accessibility

Triple signaling is mandatory: color, icon, and text label. Under deuteranopia the pending yellow and completed green converge — the icon and the word are what survive. See Status indicators.

Keyboard

Not focusable and not interactive. The row or detail view that contains it owns the interaction.

Tokens

--ds-warning-bg · -text · -icon · --ds-info-* · --ds-success-* · --ds-error-* · --ds-surface · --ds-muted · --ds-radius-full · --ds-text-xs · --ds-text-sm — rendered through .snc-badge and .snc-badge-{status}

Amount input

Combines a large numeric input with a currency tag. Shows live conversion rate below.

• Input accepts numbers only with auto-formatting
• Currency tag is tappable to switch currencies
• Conversion rate updates in real time
• Supports both fiat and crypto amounts

Anatomy

┌──────────────────────────────────────┐
│  You send                            │  label, --ds-text-sm
│  ┌────────────────────┐  ┌────────┐  │
│  │  1,250.00          │  │ 🇺🇸 USD ▾│  │  --ds-text-display / 700
│  └────────────────────┘  └────────┘  │  currency tag, tappable
│  ≈ 2,062,500.00 NGN                  │  --ds-text-sm, --ds-muted
│  Rate 1 USD = 1,650.00 NGN           │  --ds-text-xs, --ds-muted
└──────────────────────────────────────┘

The editable value is a single text run at one size. The cents step-down in Typography applies to amounts that are displayed, not to an amount being typed — an <input> cannot render two sizes.

Variants

API

interface CurrencyOption {
  code: string;                     // ISO 4217, or a product-owned code for crypto
  kind: "fiat" | "crypto";          // decides minor-unit source and whether a flag is expected
  name: string;                     // "Nigerian Naira" — also the spoken form in descriptions
  minorUnits: number;               // 2 USD, 0 JPY, 8 BTC — see Tokens > Currency minor units
  flag?: string;                    // ISO 3166-1 alpha-2; omitted for crypto
  keywords?: string[];              // extra search terms — country names, "naira"
  rateLabel?: string;               // pre-formatted, shown in the picker — "1 USD = 1,650.00"
}

interface RateQuote {
  rate: number;
  quotedAt: Date;
  expiresAt: Date;                  // quotedAt + 60s fiat, + 15s crypto
}

interface AmountInputProps extends FieldBase {   // label, hint, error, required, disabled, readOnly, name, onBlur
  value: string;                    // string, not number: a trailing "." must survive a render
  onValueChange: (value: string) => void;
  currency: CurrencyOption;
  currencies: CurrencyOption[];
  suggestedCurrencies?: string[];   // codes, rendered first in the picker — recent and likely corridors
  onCurrencyChange: (currency: CurrencyOption) => void;
  targetCurrency?: CurrencyOption;  // omit to hide the conversion line
  quote?: RateQuote;
  quoteState?: "idle" | "loading" | "live" | "expiring" | "expired" | "error";  // default: derived — see below
  onRefreshQuote?: () => void;
  max?: string;                     // balance or limit; exceeding it errors without clearing the value
  size?: "default" | "hero";        // default: "hero" on the send screen
  locale?: string;                  // default: the app locale — drives separators and decimal mark
}

Caret preservation

The field reformats as the user types, and the caret must not jump. The contract, stated because two implementations will otherwise differ on exactly the three cases users hit:

1. Count the digits before the caret, ignoring separators.
2. Reformat the whole value.
3. Place the caret after the same digit index, restoring in a layout effect so no intermediate position paints.

States

Behavior

• Input is inputmode="decimal", not type="number" — a number input shows spinner arrows, accepts e and +, and behaves differently in every browser.
• Grouping separators are inserted as the user types; the caret position is preserved across the reformat.
• Precision follows the currency's minor unit: 2 for USD, 0 for JPY, 8 for BTC. A crypto amount and a fiat amount are not the same field with a different label.
• The conversion line updates on a debounce, never on every keystroke.
• Crossing the balance or a limit shows the error inline and keeps the entered value. Clearing a user's input because it was too large is how a user loses the amount they had just worked out.

Currency picker

Tapping the currency tag opens a Sheet. It is the only picker this component uses.

────────────────────────────────────────
  Choose currency                    ✕
  🔍 Search currency or country
  Suggested
   🇳🇬  NGN   Nigerian Naira    1 USD = 1,650.00
   🇵🇭  PHP   Philippine Peso   1 USD = 56.20
  All currencies
   🇦🇪  AED   UAE Dirham        1 USD = 3.67
   …
────────────────────────────────────────

The list uses the listbox pattern inside the dialog: role="listbox" on the list, role="option" on rows, aria-activedescendant from the search input. The result count is announced politely as the query changes.

Structure: one listbox containing two role="group" elements labelled "Suggested" and "All currencies"; only the second while a query is present. ↑ ↓ do not wrap, and Home / End go to the first and last row. When the sheet opens, the active row is the selected currency. The active row takes --ds-surface; the selected row also shows the Check icon.

Rate freshness

A quoted rate has a validity window. When it expires the conversion line is struck through and a refresh action appears; the stale number is never shown as current. If the rate changes materially between quote and confirmation, the confirm step re-quotes and states the change rather than silently charging the new rate.

Content

The label says what the amount is for — "You send", "They receive" — never "Amount".

Copy

Accessibility

• Visible label above the field — never a placeholder as the label.
• The conversion line and rate are attached via aria-describedby, so they are read with the field.
• Rate updates are announced politely, throttled. A rate refreshing every 30 seconds on an assertive region would interrupt the user continuously.
• The currency tag is a <button>. Its visible text is the code ("USD"); a visually hidden suffix completes the name — "USD, US Dollar, change currency" — so the accessible name contains the visible text (SC 2.5.3). It carries aria-haspopup="dialog" and aria-expanded while the picker is open.
• The field's value is read as typed — a text input's value cannot be given a different spoken form. The currency is carried by the field's description instead. aria-describedby references, in order: the error if present, the currency's name, the conversion line, the rate line, then the hint.
• The conversion line renders its visible short form (≈ 2,062,500.00 NGN) as aria-hidden and a visually hidden spoken form beside it ("approximately 2,062,500.00 Nigerian Naira"), because "≈" and currency codes are read inconsistently across screen readers.

What VoiceOver reads on focus:

You send, 1,250.00, text field, US Dollar, approximately 2,062,500.00 Nigerian Naira, rate 1 US Dollar equals 1,650.00 Nigerian Naira

The spoken-currency rule for amounts that are displayed rather than typed — balances, receipts, fee rows — is in Typography.

Keyboard

Tokens

.snc-amount-input · .snc-amount-field · .snc-amount-currency-tag · .snc-amount-conversion · .snc-currency-code · .snc-currency-flag

Transaction row

Displays a single transfer in the mobile transaction history. Shows recipient avatar, name, date, amount, currency, and status badge.

• Rows are tappable to view transfer details
• Amount is right-aligned for scannability
• Status badge is always visible without scrolling

Anatomy

┌────────────────────────────────────────────┐
│ (🇳🇬)  Maria Santos          -250.00 USD    │  60px min-height
│       Bank transfer · 12 Mar   [Completed]  │
└────────────────────────────────────────────┘
   36px      14px/600 name        16px/700 amount
   flag      12px/400 meta        status badge

Variants

API

interface TransactionRowProps {
  recipientName: string;
  countryCode: string;              // ISO 3166-1 alpha-2 — renders the flag, decorative
  method: string;                   // "Bank transfer", "Mobile money"
  amount: string;                   // pre-formatted, including the currency code
  direction: "out" | "in";
  status: TransferStatus;
  date: Date;
  href: string;                     // the row is one link; there is no second action inside it
}

States

On hover and press the row background equals a Cancelled badge's background, so that chip's edge disappears (1.00:1). This is accepted: the badge's icon and label stay at 5.04:1 against the same surface, and they — not the chip's edge — carry the status.

Behavior

• The whole row is one control. There is no secondary action inside it — a row with a tappable region and a non-tappable region is a row users tap in the wrong place.
• The amount carries its currency code and its direction. A bare number in a multi-currency history is unreadable.
• Status is visible without expanding. The reason this row exists is to answer "did it arrive?".
• Under Save-Data or offline the flag falls back to a country-code circle. The row loses nothing that matters.

Content

The amount carries a sign and a currency code. The meta line is method and date, in that order — the method is what a user checks when a transfer is slow.

Accessibility

• Rendered as a <button> or <a> wrapping the row content, with one accessible name that reads as a sentence: "Maria Santos, 250 dollars, sent 12 March, completed."
• The flag is decorative (alt="") because the country is already in the accessible name.
• The status badge is part of the row's name, not a separately focusable element.
• 60px height exceeds the 48px touch minimum.

Keyboard

Tokens

.snc-tx-row · .snc-tx-avatar · .snc-tx-name · .snc-tx-meta · .snc-tx-amount · .snc-tx-currency · .snc-tx-details · .snc-tx-value

Transfer stepper

Vertical step indicator for the transfer flow. Shows completed, active, and upcoming steps with connecting lines.

• Steps: Send → Review → Confirm
• Completed steps show a check icon
• Active step is highlighted with primary color
• Upcoming steps are muted

Anatomy

Dot, connecting line, label, optional timestamp per step. Completed dots are 24px with a check; active and future dots are 12px.

Variants

API

interface TransferStepperProps {
  steps: Array<{ id: string; label: string }>;   // 3 maximum
  currentIndex: number;
  completedIndices: number[];
  errorIndex?: number;
  onStepSelect?: (index: number) => void;        // called only for completed steps
  orientation?: "horizontal" | "vertical";       // default: "horizontal"
}

Upcoming steps are aria-disabled and are never passed to onStepSelect. The component does not advance itself.

States

The active dot pulses. Under prefers-reduced-motion the pulse stops and the state is still carried by fill color, the icon, and the step label — motion is never the only signal.

Behavior

• Completed steps are tappable and return to that step with data intact. Upcoming steps are not reachable.
• The stepper never advances on its own. Only a user action moves it forward.
• Three steps is the ceiling. A fourth step means the flow needs redesigning, not a longer stepper — see Design principles.

Content

Step labels are one or two words: "Send", "Review", "Confirm". Timestamps in the vertical variant are absolute, not relative — "14:32, 12 Mar", not "2 hours ago".

Accessibility

• Ordered list, so position and count are structural.
• aria-current="step" on the active step.
• Upcoming steps are aria-disabled, not removed from the tab order.

Keyboard

Tokens

--ds-timeline-completed-dot · --ds-timeline-completed-icon · --ds-timeline-active-dot · --ds-timeline-future-dot · --ds-timeline-line-completed · --ds-timeline-line-default · --ds-timeline-pulse-color

Camera capture

Visual KYC viewfinder component with two variants: document (ID card frame with corner marks) and selfie (circular frame). Designed as a showcase pattern — no native camera API.

• Document variant: rectangular frame with 856:540 aspect ratio (standard ID) and L-shaped corner marks
• Selfie variant: circular frame (160px diameter) with round border
• Shutter button: 64px double-circle pattern (outer ring + inner fill)
• Captured state switches to "Use Photo" and "Retake" buttons
• Self-contained dark UI — no dark mode override needed

Why the chrome is fixed dark

Camera surfaces use --ds-camera-bg (#111827) in both themes. A viewfinder that inverts in light mode costs the user their frame of reference and gains nothing — the subject of the screen is the camera feed, not the interface. This is one of two sanctioned exceptions to theme remapping, recorded in Tokens.

Anatomy

Fixed-dark surface, frame overlay, hint text above the shutter, 64px double-circle shutter, manual upload link below.

Variants

API

interface CameraCaptureProps {
  variant: "document" | "selfie";
  captured?: string;                // data URL or object URL; presence switches to the review state
  onCapture: () => void;
  onRetake: () => void;
  onConfirm: () => void;
  onManualUpload: () => void;       // required — a capture-only flow excludes users who cannot operate a camera
  hint?: string;                    // shown before capture, not after rejection
}

States

Behavior

• The frame matches the document shape (856:540 for an ID card, circular for a selfie). A capture frame that does not match the document produces uploads that verification rejects.
• The captured state is reviewable before submission. "Use photo" and "Retake" are both present, and neither is pre-selected.
• Guidance ("Fit your ID inside the frame") is visible before capture, not surfaced as an error after rejection.

Content

The hint says what a good capture looks like — "Fit your ID inside the frame, all four corners visible" — before capture, not as an error afterwards.

Accessibility

• The shutter button has a variant-specific aria-label — "Take photo of ID", "Take selfie" — not "Capture".
• Frame corner marks are decorative and aria-hidden.
• Capture success is announced politely.
• A manual upload path exists for users who cannot operate a camera. A capture-only KYC flow excludes people with motor or vision impairments from the product entirely.

Keyboard

Tokens

--ds-camera-bg · --ds-camera-overlay · --ds-camera-frame · --ds-camera-frame-active · --ds-camera-capture-bg · --ds-camera-capture-border · --ds-camera-retake-bg · --ds-camera-hint

QR scanner

QR code scanner viewfinder with animated scan line. Shows scanning and success states. Includes optional manual entry link.

• Square scan window: 65% parent width, max 280px
• 4 L-shaped corner marks (28px)
• Animated scan line moves top-to-bottom repeatedly
• Success state: green check icon replaces scan line, corners turn green
• Manual entry button with keyboard icon
• Self-contained dark UI — no dark mode override needed

Manual entry is required, not optional

The manual entry link is part of the component, not a fallback. Scanning fails on cracked screens, in low light, with a damaged printed code, and for anyone who cannot hold a phone steady — all common in Senco's audience. A scanner without a typed alternative is a dead end.

Anatomy

Fixed-dark surface, square scan window at 65% width capped at 280px, four 28px corner marks, animated line, hint, manual entry button.

Variants

One. A scanner that cannot fall back to typing is not a variant, it is a defect.

API

interface QRScannerProps {
  state: "scanning" | "success" | "error";
  onScan: (value: string) => void;
  onManualEntry: () => void;        // required, not a fallback
  hint?: string;
  errorMessage?: string;
}

States

Behavior

• The scan line loops continuously while scanning and stops on success.
• Success turns the corner marks green and shows a check icon and announces. Color alone does not confirm.
• Under prefers-reduced-motion the scan line is static; scanning still works and is announced.

Content

The instruction names what to point at. The manual entry control says what it does — "Enter the address instead" — never "Having trouble?".

Accessibility

• The scanner region has an accessible name and a text instruction.
• Success and failure are announced through a polite live region.
• The manual entry control is a real button with a 48px target.
• The animated line is decorative and aria-hidden.

Keyboard

Tokens

--ds-qr-bg · --ds-qr-overlay · --ds-qr-frame · --ds-qr-scan-line · --ds-qr-hint · --ds-qr-manual-link

Receipt view

Compound component displaying transfer receipts with status header, tear-line separator, key-value rows, and action footer.

Sub-components:

• ReceiptView — root container with status header
• ReceiptViewSection — grouped rows with optional title
• ReceiptViewRow — label + value pair using dl/dt/dd semantics
• ReceiptViewActions — footer with action buttons

Structure:

• Header: status icon + title + subtitle (date)
• Tear line: CSS radial-gradient scalloped edge
• Body: key-value rows in sections
• Footer: download/share buttons

What a receipt must contain

A receipt is the artifact a user forwards to their bank, their family, or support. It is the only screen in the product that has to be complete out of context:

The rate shown is the rate that was applied, permanently. A receipt that re-renders with today's rate is not a receipt.

Anatomy

Status header with icon, title, and date; a scalloped tear line; body sections of label-value rows; a footer with download and share.

Variants

API

interface ReceiptViewProps {
  status: TransferStatus;
  reference: string;                // the only value support can search on
  timestamp: Date;
  sections: Array<{
    title?: string;
    rows: Array<{ label: string; value: string; emphasis?: boolean }>;
  }>;
  onDownload?: () => void;
  onShare?: () => void;
  rendering?: "screen" | "export";  // default: "screen"; "export" switches to the documentation font stack
}

Values are pre-formatted strings, and the rate shown is the rate that was applied. A receipt that re-derives its rate at render time is not a receipt.

States

Behavior

• Exported receipts use the documentation font stack (Arial), not system-ui, so a PDF renders identically everywhere. See Typography.
• The tear line is a CSS gradient, not an image. The receipt renders completely with zero images loaded.
• Download and share are separate actions — share invokes the OS sheet, download writes a file.

Content

Every row in the Receipt contents table above is required. A receipt missing its reference number cannot be used with support, which is most of what a receipt is for.

Accessibility

• Semantic <article> root with <dl> / <dt> / <dd> for key-value pairs, so a screen reader pairs each label with its value instead of reading two unrelated columns.
• The tear line is decorative and aria-hidden.
• Amounts use tabular-nums and are announced with their currency.
• The status icon is aria-hidden; status is text in the header.

Keyboard

Tokens

--ds-receipt-bg · --ds-receipt-border · --ds-receipt-header-bg · --ds-receipt-icon-success · --ds-receipt-label · --ds-receipt-value · --ds-receipt-divider · --ds-receipt-footer-bg · --ds-receipt-tear

Contact card

Tappable card displaying a contact's avatar, name, country flag, payment method, and optional detail. Used in the recipient selection grid on the Send start screen.

Visual structure

• Vertical flex layout, center-aligned
• Avatar at top with initials fallback
• Name, payment method with country flag, optional detail
• Hover: background and shadow transition

Anatomy

Avatar or initials at the top, name, method with country flag, optional masked detail. Centre-aligned in the grid variant.

Variants

API

interface ContactCardProps {
  name: string;
  countryCode: string;
  method: string;                   // selecting a contact selects a contact *and* a rail
  detail?: string;                  // masked account fragment
  avatarUrl?: string;               // falls back to initials — the normal case under Save-Data
  selected?: boolean;
  onSelect: () => void;
}

States

Hover raises the shadow and never changes the border. Border change means selected, and the two states have to stay distinguishable — a user picking a recipient for a payment must be certain which one is chosen.

Behavior

• The avatar falls back to initials when no image loads, which is the normal case under Save-Data.
• The payment method is shown on the card, because the same person can be a recipient by bank transfer and by crypto with different fees and arrival times. Selecting a contact selects a contact and a rail.
• Selecting a card advances the flow immediately. It is a choice, not a form field awaiting submit.

Content

The method is shown, not implied. The same person by bank transfer and by mobile money are two different choices with different fees.

Accessibility

• Rendered as a <button> with an accessible name covering everything visible: "Maria Santos, Nigeria, bank transfer."
• The flag is decorative; the country is in the name.
• 48px minimum target; the card is considerably larger.
• Selection state is conveyed by aria-pressed or by radio semantics when the grid is a single-choice group.

Keyboard

Tokens

--ds-contactcard-bg · --ds-contactcard-border · --ds-contactcard-hover-bg · --ds-contactcard-hover-shadow

Design and accessibility

• Status badges use color + dot + text — accessible to color-blind users
• Amount input has visible label and aria-describedby for conversion rate
• Transaction rows are keyboard-focusable with enter to view details
• Touch targets are 48px minimum on all interactive elements
• Camera capture shutter button has descriptive aria-label per variant
• QR scanner scan-line animation respects prefers-reduced-motion: reduce
• Receipt view uses semantic article root, dl/dt/dd for key-value pairs
• Contact card uses <button> element for full keyboard accessibility

Rules specific to money components

• Every amount states its currency. No exceptions anywhere on this page.
• Sent is not completed. Green is reserved for money the recipient has.
• A quoted rate carries its validity. Stale rates are struck through, never shown as current.
• Every scan or capture has a typed alternative. A camera-only path excludes users the product must serve.
• Amounts use tabular-nums so columns align and an outlier is visible.
• A user's entered amount is never cleared by a validation error.

Do and don't

Known gaps

• Camera capture is a visual showcase with no native camera integration.
• Crypto precision (8 decimals) is specified for Amount input but no crypto-specific component variant is documented.
• No component here documents its offline state explicitly, though the patterns describe them.
• .snc-* classes are the implementation surface; several have no corresponding --ds- token.
